Description

UTX018 is a Polyimide film that has been coated with an anti-static silicone adhesive. The adhesive has been highly loaded with conductive particles in order to achieve the maximum static dissipation.

Backing: Polyimide Film
Adhesive: Silicone
Surface Resistivity: 10³ – 104 ohms
Backing Thickness: 1.0 mil (0.025 mm)
Adhesive Thickness: 1.2 mil (0.035 mm)
Adhesion to Steel 180 degree Peel: 9 oz/inch (1N/cm)
Operating Temp: up to 260°C short term
Elongation at Break: NA
Tensile Strength: 28 lbs./in (50 N/cm)
Length: 36 yard
Available Colors: Bronze (BZ)

OPTIONS:

Color Options: Bronze (BZ)

Standard Size Options: 0.75”, 1.00”, 2.00”

Cleanliness Levels
  *   [UltraClean Cleanliness at UltraTapeClick and drag to move] UltraClean | Class 1 (ISO Class 3) to Class 1,000 (ISO Class 6) Standards
  *   Classic Clean | Class 10,000 (ISO Class 7) to Class 100,000 (ISO Class 8) Standards

* Samples are available for most products upon request
